Auto pipe bender
AUTO38
Shuztung provides Auto Pipe Bender and fully auto CNC bender with PC base control for multiple bending purpose and equiped with 3D simulation function.
| Specifications | AUTO 38 | |
|---|---|---|
| HORSE POWER | 6HP | |
| MAX. BENDING CAPACITY(mm) | 38x2 | |
| MAX. BENDING RADIUS(mm) | 180 | |
| MAX. BENDING ANGLE(°) | 190 | |
| MAX. FEEDING POSITIONING LENGTH(mm) | 2000 | |
| MAX. FEEDING LENGTH WITH MANDREL(mm) | 2900 | |
| BENDING ACCURACY(°) | ±0.2 | |
| BENDING SPEED(°/sec) | 4 | |
| FEEDING ACCURACY(mm) | RACK | ±0.2 |
| BALLSCREW | - | |
| FEEDING SPEED(mm/sec) | 1~500 | |
| TURNING ACCURACY(°) | ±0.2 | |
| NUMBER OF PROGRAMS | 50 | |
| BENDING NO./PROGRAM | 15 EDIT LINES / PROGRAM | |
| TURNING SPEED(°/sec) | 120 | |
| RADIUS DIFFERENCE BETWEEN STACKS(mm) | ||
| DIMENSIONS(cm) | 390x110x130 | |
| WEIGHT (kg) | 2000 | |
